Electric circulation heaters or flow-through devices are designed for heating liquids such as water, oil, etc. Available in various sizes, capacities, and controls. Suitable for industry, shipping and marine applications, catering and large kitchen industry, ask for the possibilities.
DSA 5: circulation heater 200kW-3x400V + control
DSA 5: circulation heater 200kW-3x400V + control
• Power up to 250 kW-3×400 or 3x440V, including control in several stages(± 8)
• Made with stainless steel 304/316L, connections according to desired specifications, including frame
• Optional: PLC control, extensive security, flow monitoring, etc.
• Application: water, water-glycol or oil, central heating
DSA 7: circulation heater 232 kW-3x380V RAL 9010
DSA 7: circulation heater 232 kW-3x380V RAL 9010
• Model 232kW-3x380V, stainless steel 304 painted RAL 9010, suitable for water/glycol.
• 4 stages 58kW, IN/OUT DN200, dimensions ± 1950x950x1330mm
• Built from 2 tanks, including frame, control box, extensive control, security, etc.
• Inlet and outlet connections optional at desired specification. (welding sock / flange plate)
• At desired specification up to 250kW with PLC control and flow monitoring
DSA 13: circulation heater 360kW-3x400V
DSA 13: circulation heater 360kW-3x400V
• Execution in AISI 304, uitable for water or water/glycol heating etc.
• built up of 4 tanks, including frame
• connections in- and outlet on specification
• Optionally with control cabinet
DSA 14: circulation heater 435kW-3x400V
DSA 14: circulation heater 435kW-3x400V
• Execution in AISI 304, painted RAL 9016 suitable for water or water/glycol heating etc.
• built up of 4 tanks, including frame, limit thermostats and overpressure protection
• connections in- and outlet NW65 or on specification
• Optionally with control cabinet, flow control, level sensor
• Model: 435kW – 3x400V, 16 stages 16,7 kW
DSA 15: circulation heater 200kW-3x400V + control
DSA 15: circulation heater 200kW-3x400V + control
• Execution in AISI 304, incluing control suitable for water or water/glycol heating etc.
• Built up of 2 tanks, including frame, flowcontrol, overpressure protection, butterfly valves
• Connections in- and outlet NW100 or on specification
• With control cabinet
• Model: 200kW – 3x400V in 5 stages 50/37,5/12,5 kW
DSA 16: circulation heater 250kW-3x400V + control
DSA 16: circulation heater 250kW-3x400V + control
• Execution in AISI 304, incluing control suitable for water or water/glycol heating etc.
• Built up of 2 tanks, including frame, overpressure protection and temperature control
• Connections in- and outlet NW100 or on specification
• Model: 250kW – 3x400V in 6 stages
DSA 17: circulation heater 205kW-3x400V
DSA 17: circulation heater 205kW-3x400V
• Execution in AISI 304, white painted suitable for water or water/glycol heating etc.
• Built up of 2 tanks, including frame, overpressure protection and max. temperature control, no control
• Connections in- and outlet NW65 or on specification
• Model: 205kW – 3x400V in 10 stages
DSA 18: Cicrulation heater 200kW-3x400V +control, isolated
DSA 18: Cicrulation heater 200kW-3x400V +control, isolated
• Made of stainless steel 304, insulated version, suitable for water or water glycol heating
• Made up of 2 tanks, including frame, overpressure protection, temperatuur control with digital read out, temperature protection, butterfly valves
• In- and oulet connections NW 100
• Model: 200kW – 3x400V in 5 steps
